Zycoo UMTS - Module de UMTS (LTE) 1 puce GSM pour connection data a traver le reseau GSM au Zycoo CoVox U20, U50, U60 et U100

Chargement...Chargement...
-39%
Module de UMTS (LTE) 1 puce GSM pour connection data a traver le reseau GSM au Zycoo CoVox U20, U50 et U100

Prix Normal : 2 899,00 Dh HT

Prix :2 199,90 Dh HT

Prix Promo : 1 759,92 Dh HT

2 111,90 Dh TTC

Economie : 1 139,08 Dh - 39%

UMTS LTE module pour 3G WCDMA data access pour les IPBXs CoVox (U20/50/60/100)

Disponibilité : Nous consulter sur mv.ma
Evaluation :
  • Module de UMTS (LTE) 1 puce GSM pour connection data a traver le reseau GSM au Zycoo CoVox U20, U50 et U100
 Description
UMTS module for 3G WCDMA data access(For U20/50/100)


The GSM module supports CooVox-U20 IP Phone System for GSM connection. Each port has one LED(Light-Emitting Diodes).
Designed with SIM900 for global market, SIM900 is a quad-band GSM engine that works on frequencies GSM 850MHz, EGSM 900MHz, DCS 1800MHz and PCS 1900MHz.


Fiche Technique
The GSM module supports CooVox-U2 Ip Phone Systemfor GSM connection. Each port has one LED(Light-Emitting Diodes), which is assembled on the mainboard.
The Red LED indicates port status:
• Solid Red= Module loading successful
• Blink Red= Channel Ringing
If the LED is off, the GSM module is loading failure.


The Red LED indicates port status:
• Solid Red= TE Model
The Green LED indicates port status:
• Solid Green= NT Model
If the LED is off, the module is loading failure.



SIM900 key features

Feature

Implementation

Power supply

Single supply voltage 3.4V-4.5V

Power saving

Typical power consumption is SLEEP mode is 1.5mA(BS-PA-MFRMS=5)

Frequency Bands

SIM900 quad-band:GSM850, EGSM 900, DCS 1800, PCS 1900. The SIM900 can search the 4 frequency bands automatically.

Compliant to GSM Phase 2/2+

GSM class

Small MS

Transmitting power

Class 4(2W) at GSM 850 and EGSM 900

Class 1(1W) at DCS 1800 and PCS 1900

Temperature range

Normal operation: -30-+80 degrees Centigrade






Téléchargements


iconCooVox_UMTS 3G Module Datasheet.pdfTélécharger
