OpenVox SWG-1016G
Menu-
Passerelle 16 Ports GSM VoIP GSM Gateway 16 GSM Channels
En Arrivage
18 999,00 Dh HT
13 499,00 Dh HT
10 799,20 Dh HT
12 959,04 Dh TTCProduct Spotlight
OpenVox SWG-1016G gateway supports 16 GSM Channels and 1 Ethernet interface, And the band is 850/900/1800/1900 MHz.
SWG-1016G gateway supports multiple codecs, including G.711U, G.711A, GSM, G.722, G.723, G.726, G.729 multiple coding. The GSM gateway will be 100% compatible with Asterisk, FreePBX, Elastix, Trixbox, 3CX, FreeSWITCH SIP server and VOS VoIP operating platform. It can help users reduce telecommunications and communication costs.
Technical Specifications
- 16 GSM Channels
- 1 SIM card per GSM channel
1 10/100M LAN interfaces- 16 Standard SMA-K interfaces
- LCD dimension:2.4"
- LCD resolution ratio: 240*400
- Storage temperature range: -20~70℃
- Operation temperature range: 0~40℃
- Operation humidity range: 10%~90% non-condensing
- Power source: 12V DC/2.33A
- Power: 36W
- Dimension: 36cm*21cm*4.44cm
- Weight: 1.544Kg
- Compatible with Asterisk, Elastix, FreePBX, 3CX, FreeSWITCH Sip Server
System Features
- Abundan
t Codecs：G.711U，G.711A，GSM，G.722，G.723，G.726，G.729 - Simple and convenient configuration via Web GUI
- Firmware Update by HTTP
- Automatically Reboot
- Support DISA
- Mutiple Detailed LOG Output
- Call Status Display
- Mobile number portability（MNP）
- CDR
- Support Configuration files backup and upload
- Support for Custom scripts, diaplans
- Restore Factory Settings
VoIP Characters
- Support SIP, IAX2 Protocol
- Add, Modify & Delete SIP/IAX2 Trunk
- SIP/IAX2 Registration with Domain
- DTMF Mode：RFC2833/Inband/SIPInfo
- Multiple SIP/IAX2 Registrations modes
GSM Features
- CallerID Display & Hide
- GSM ：850/900/1800/1900 MHz
- Real Open API Protocol
- Call Duration Limitation
- SMSC/SMS/USSD
- PIN Identification
- Voice Codec
- Ports Group Management
- SMS Remotely Controlling Gateway
- SMS Bulk Transceiver, Sent to Email and Auto- Matically Resend
- SMS Forwarding and Quick Reply
Network
- IPv4，UDP/TCP，DHCP，TELNET，HTTP/HTTPS，TFTP
- HTTP/SSH（Optical Telnet)
- Ping & Traceroute Command on the Web
- Simple Security Strategy: white list, black list, security rules
